Designed with safety in mind, the High Speed PVC Roller Door features obstacle detection sensors that prevent accidents and ensure safe passage. Its advanced insulation properties help maintain stable indoor temperatures, reducing energy costs while enhancing work environment comfort.
Feel free to contact us for further queries.
CI Industry, a leading producer of High Speed PVC Roller Doors, is dedicated to delivering state-of-the-art and high-quality products to meet the varied demands of commercial and industrial customers. Reach out to us to select from an array of sizes and customization options that will seamlessly complement your home's design.
Product Name | High Speed PVC Roller Door |
Maximum Door Size | W6500mm*H6000mm |
Opening speed | 0.8 - 2.0 m/s, adjustable |
Closing speed | 0.6 - 1.0 m/s, adjustable |
Operation way | Remote control, wall switch, Magnetic loop, Radar, Pull Rope Switch, Signal lamp |
Emergency Operation | Available with manual crank |
Curtain Thickness | 0.8 / 1.0 / 1.2 / 1.5mm |
Hardware Material | Frame and Cover Box - Galvanized steel / 304 stainless steel |
Track Guide - Galvanized Steel / 304 Stainless Steel / Aluminum extrusion | |
Wind Resistance Bar - Aluminum Extrusion | |
Curtain - SIOEN high strength polyester textile fiber | |
Vision panel - 1.5mm thick transparent PVC | |
Motor Brand | SNMA, SEW, SIEMENS,SEJ,SERVO |
Motor Power | 0.75kw - 5.50kw |
Input Voltage | 220V 50HZ/380V 50HZ |
PLC Brand | SIEMENS / MIT-SUBISHI / OMRON /KEWEI |
Inverter / AC Driver | MIT-SUBISHI, SIEMENS, SHIHLIN |
Control Box Finish | Powder coated steel /304 stainless steel |
Safety Performance | Infrared photo sensor, Safety airbag edge protection |
Tolerance Frequency | 2 times/min, Inverter opening 2500-3000 times/day |
Safety Class | IP55 |
Wind Resistance | Class 5-8 (Beaufort Scale) |
Operating Life | 500,000 cycles |
Working Temperature | -25 °C to 65 °C |
Warranty | 1 year for electric parts, 5 years for mechanical parts |
Maximum Size: 6500mm x 6000mm
Opening Speed: Up to 1.9m/s, variable
Temperature Resistance: -25°C to +65°C
Wind Resistance: Available up to Class 8 (Beaufort Scale)
Weight: Canvas 950g / M2
Steel Construction: Galvanized Steel with Full Cover
Vision Window: Available
